4 Bar Aluminum Alloy Pediatric Knee Joint For Max Load 45Kg 90lbs
• Pediatric polycentric 4-bar knee
(Pediatric) Red Color AA7075 Aluminium Max Load 45Kg 90lbs
• Polycentric • With integrated Adjustable spring extension assist
• Suitable for max. 45 kg (90Lbs) body weight
Recommendation:
• For trans-femoral amputees • With moderate functional levels
• Medium stance phase stability • Medium swing phase control
• Light weight
• Not suitable for amputees with higher functional levels
• Optional Adapters: Pyramid (AK) and J adapter (KD)
Description:
Upper and lower joint section is connected with linkage bars. The stance phase stability is achieved with the polycentric kinematic ( Adjustment of the instant center of rotation by adjustment of the stop). The stepless adjustment of the axis friction and of the extension assist spring controls the swing phase.
Technical Data:
• Knee flexion range: approx. 165°
| Product Number | Material | Standard | Part Weight | Weight Limit |
| 4P15AL | Aluminum alloy | — | 300g | 45Kg/99lbs |
