Home /Products/Prosthetic Knee Joint/Stainless Steel Self Lock Prosthetic Knee Joint Single Axis

Stainless Steel Self Lock Prosthetic Knee Joint Single Axis

5 Pcs
MOQ
USD 60~40 Per Pcs
Price
Stainless Steel Self Lock Prosthetic Knee Joint Single Axis
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Stainless Steel
Connections: AK
Weight: 669g
Weight Limit: 100Kg / 220Lbs
Activity Level: K1,K2
Maximum Knee Flexion Angle: 150°
Knee Center To Proximal Connection: 40mm
Proximal Connection: Pyramidal Adaptor
Distal Connection: Pyramidal Adaptor
Warranty: Two Years
Basic Infomation
Place of Origin: CHINA
Brand Name: HK PROSTHETIC ORTHOTICS
Certification: CE And ISO13485
Model Number: CHG-01S
Payment & Shipping Terms
Packaging Details: Shaped EPE With Cartons
Delivery Time: Within 7 Work Days
Payment Terms: T/T, Western Union,
Supply Ability: 1000000 Pcs Per Year
Product Description

Prosthetic Knee Joint-Single Axis Knee Joint With Self-Lock Stainless Steel Max body weight 100Kg



Suitable for max. 100 kg (220lbs) body weight
Recommendation:
• For trans-femoral amputees • With moderate functional levels
• High stance phase stability • Moderate swing phase control
• Not suitable for amputees with higher functional levels
Description:
The connection between upper and lower joint section is generated by the swing- and friction axis and
operates as a load dependend brake. This secures, in combination with the posterior positioning, the stance
phase. The adjustment of the axis friction and spring load
controls the swing phase.
Technical Data:
• Knee flexion range: approx. 150° • Height (knee center - upper edge): 40 mm
Product Number Material Standard Part Weight Weight Limit
CHG—01S Casting S.Steel Work with CHF-01 669g 220lbs



Stainless Steel Self Lock Prosthetic Knee Joint Single Axis
Stainless Steel Self Lock Prosthetic Knee Joint Single AxisStainless Steel Self Lock Prosthetic Knee Joint Single Axis







Stainless Steel Self Lock Prosthetic Knee Joint Single Axis
